RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing MAC Addresses 687
Figure 806: DSCP to CoS Mapping Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen DSCP.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.33
Managing MAC Addresses
The following sections describe how to configure and manage MAC addresses:
• Section 5.33.1, “Viewing a Dynamic List of MAC Addresses”
• Section 5.33.2, “Purging the Dynamic MAC Address List”
• Section 5.33.3, “Configuring MAC Address Learning Options”
• Section 5.33.4, “Managing Static MAC Addresses”
Section 5.33.1
Viewing a Dynamic List of MAC Addresses
To view a dynamic list of learned and statically configured MAC addresses, navigate to switch » mac-tables »
mac-table. If MAC addresses have been learned, the MAC Address Table appears.
