Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
526 Configuring Match Rules
Section 5.21.6.7
Configuring Match Rules
To configure match rules for a route map filter entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » ospf » filter » route-map » {tag} » entry » {number} » match, where
{tag} is the tag for the route map filter and {number} is the sequence number for the entry. The Match
Address of Route, Match Nexthop of Route, Match Advertising Source Address and Match forms
appear.
Figure 606: Match Address of Route Form
1. Prefix List List
Figure 607: Match Nexthop of Route Form
1. Prefix List List
Figure 608: Match Interface Form
1. Interface Name List
3. On the Match Address of Route form, configure the following parameters as required:
Parameter Description
Prefix List The prefix list name.
4. On the Match Nexthop of Route form, configure the following parameters as required:
