Chapter 4
System Administration
RUGGEDCOM ROX II
User Guide
204 Deleting a Private Key
Figure 215: Private Key Form
1. Algorithm List 2. Contents Box
5. In the Private Key form, configure the following parameters as required:
Parameter Description
algorithm Synopsis: rsa, dsa
The type of key.
Contents Synopsis: The aes-cfb-128-encrypted-string works exactly like des3-cbc-encrypted-
string but AES/128bits in CFB mode is used to encrypt the string. The prefix for
encrypted values is '$4$'.
The contents of the unsigned private key.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 4.7.2.3
Deleting a Private Key
To delete an unsigned private key, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » crpto » private-key. The Private Key table appears.
