RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Static MAC Address 693
Section 5.33.4.3
Deleting a Static MAC Address
To delete a static MAC address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to switch » mac-tables » static-mac-table. The Static MAC Address Parameters table appears.
Figure 815: Static MAC Address Parameters Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen static MAC address.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.34
Managing Spanning Tree Protocol
The following sections describe how to configure and manage STP:
• Section 5.34.1, “RSTP Operation”
• Section 5.34.2, “RSTP Applications”
• Section 5.34.3, “MSTP Operation”
• Section 5.34.4, “Fast Root Failover Operation”
• Section 5.34.5, “Configuring STP Globally”
• Section 5.34.6, “Configuring STP for Switched Ethernet Ports”
• Section 5.34.7, “Configuring STP for Ethernet Trunk Interfaces”
• Section 5.34.8, “Managing Multiple Spanning Tree Instances”
• Section 5.34.9, “Managing Port Costs and Priorities”
• Section 5.34.10, “Viewing the Status of RSTP”
• Section 5.34.11, “Viewing RSTP Per-Port Statistics”
