RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring a Black Hole Connection for an IPv4 Static
Route 541
Figure 627: Static Route Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen route.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.22.5
Configuring a Black Hole Connection for an IPv4 Static
Route
To configure a black hole connection for an IPV4 static route, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » static » ipv4 » {subnet}, where subnet is the subnet (network/prefix) of the static
route.
3. Click the + symbol in the menu next to blackhole. The Blackhole Static Route form appears.
Figure 628: Blackhole Static Route Form
1. Distance Box
4. Configure the following parameter(s) as required:
Parameter Description
Distance (optional) Default: 1
