Siemens RX1500

RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring a Routing Interface 505
Section 5.20.11.2
Configuring a Routing Interface
To configure a routing interface for a RIP network, do the following:
NOTE
OSPF regards router interfaces as either passive or active, sending OSPF messages on active
interfaces and ignoring passive interfaces.
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » rip » interface » {name}, where {name} is the name of the interface. The
Authentication and Interface Parameters forms appear.
1
2
3
Figure 580: Authentication Form
1. Mode List 2. Key Chain List 3. String Box
1
2
3
4
Figure 581: Interface Parameters Form
1. Passive Interface Check Box 2. Receive Version List 3. Send Version List 4. Split Horizon List
3. On the Authentication form, configure the following parameter(s) as required:
