Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
470 Adding an Aggregate Address
Figure 529: Aggregate Network Table
If no aggregate addresses have been configured, add addresses as needed. For more information, refer to
Section 5.19.9.2, “Adding an Aggregate Address”.
Section 5.19.9.2
Adding an Aggregate Address
To add an aggregate address for dynamic BGP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » aggregate-address and click <Add aggregate-address>. The Key
Settings form appears.
Figure 530: Key Settings Form
1. Subnet Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
subnet subnet (xxx.xxx.xxx.xxx/xx).
4. Click Add to add the address.
5. If necessary, configure options for the address. For more information, refer to Section 5.19.10.2, “Adding an
Aggregate Address Option”.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
