Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
424 Deleting an SPF Calculation Interval
Figure 464: Key Settings Form
1. Routing Type List 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Routing Type Synopsis: level-1-only, level-2-only, level-1-2
The IS type for this setting, specified as level-1-only, level-2-only or level-1-2.
4. Click Add to create the new interval. The SPF Interval Routing Type form appears.
Figure 465: SPF Interval Routing Type Form
1. Interval Box
5. Configure the following parameter(s) as required:
Parameter Description
Interval Minimum interval in seconds, ranging from from 1 to 120. Default is 1.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.18.7.3
Deleting an SPF Calculation Interval
To delete an SPF calculation interval for an IS-IS area, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
