Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
154 Viewing WAN Statistics
Parameter Description
Disabling link-alarms will prevent alarms and LinkUp and LinkDown SNMP traps from
being sent for that interface. Link alarms may also be controlled for the whole system
under admin / alarm-cfg.
alias The SNMP alias name of the interface
4. Configure a T1 or E1 line. For more information, refer to Section 3.24.6, “Configuring a T1 Line” or
Section 3.24.7, “Configuring an E1 Line”.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 3.24.3
Viewing WAN Statistics
To view statistics for the WAN network, navigate to interfaces » wan » t1e1. The T1/E1 Statistics form appears.
NOTE
Some statistics are only available for physical or logical interfaces.
Figure 161: T1/E1 Statistics Form - Physical T1/E1 Interface
1. Slot 2. Port 3. Channel Number 4. State 5. Local 6. Remote 7. Mask 8. Reliability
