RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Viewing WAN Statistics 155
Figure 162: T1/E1 Statistics Form - Logical T1/E1 Interface
1. Slot 2. Port 3. Channel Number 4. State 5. Local 6. Remote 7. Mask 8. Create Time 9. Last Status Change
This form provides the following information:
Parameter Description
slot Synopsis: sm, lm1, lm2, lm3, lm4, lm5, lm6,
Line module name of the slot.
Port Port number on the slot.
Channel Number Channel number on the port.
state Synopsis: up, down, testing, unknown, dormant, notPresent, lowerLayerDown
Status of the interface.
local Loacal IP address of the interface.
remote Peer IP address.
mask Netmask.
Reliability Reliability of the interface over 5 minutes. It is calculated as an exponential average
of the fraction of the total received and transmitted errors and the total packets that
are received and transmitted successfully.
Create Time The duration of time since interface is created.
