RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a NAT Setting 393
Figure 430: Net Address Translation Main Settings Table
If no NAT settings have been configured, add NAT settings as needed. For more information, refer to
Section 5.17.12.2, “Adding a NAT Setting”.
Section 5.17.12.2
Adding a NAT Setting
To configure a Network Address Translation (NAT) entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwnat, where {firewall} is the name of the firewall.
3. Click <Add fwnat> in the menu. The Key Settings form appears.
Figure 431: Key Settings Form
1. NAT Entry Name Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
NAT Entry Name Enter a name for this NAT entry
5. Click Add. The Net Address Translation Main Settings forms appear.
