RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Enabling/Disabling a PIM-SM Interface 557
Figure 648: Interface Table
If no PIM-SM interfaces have been configured, enable interfaces as needed. For more information about enabling
PIM-SM interfaces, refer to Section 5.24.4, “Enabling/Disabling a PIM-SM Interface”.
Section 5.24.4
Enabling/Disabling a PIM-SM Interface
To enable or disable a PIM-SM interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » multicast » dynamic » PIM-SM » interface » interface-name, where interface-name
is the name of the interface to be enabled for PIM-SM.
NOTE
A maximum of 30 non-passive interfaces can be active for PIM-SM.
3. The Interface form appears.
Figure 649: Interface Form
1. Enabled Check Box
4. Configure the following parameter(s) as required:
Parameter Description
Passive Default: true
Whether an interface is active or passive.
