Chapter 2
Using ROX II
Common Controls 21
Figure 8: Icon In a Form
The following icons appear in ROX II:
Icon Information Type
Key setting
Global setting
Operational data
Configuration data
Input data
Action
Section 2.5.6
Common Controls
The following are common controls that can be found in the ROX II Web interface.
Check Box
Click a check box to select or enable an option. Clear the check box to deselect or disable the option.
List
Select a value from a list.
