530 Adding a Redistribution Metric
Section 5.21.8.2
Adding a Redistribution Metric
To add a redistribution metric for dynamic OSPF routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » ospf » redistribute and click <Add redistribute>. The Key Settings form
appears.
1
2
Figure 613: Key Settings Form
1. Redistribute Route From List 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Redistribute Route From Synopsis: kernel, static, connected, rip, bgp
Redistributes the route type.
4. Click Add to add the metric. The Redistribute From Other Routing Protocols form appears.
1
2
3
Figure 614: Redistribute From Other Routing Protocols Form
1. Metric Type Box 2. Metric Box 3. Route Map List
5. Configure the following parameter(s) as required:
