Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
558 Configuring a Static RP Address
NOTE
Uncheck the Passive Enabled check box to activate PIM-SM on the interface, or check the
Passive Enabled check box to disable PIM-SM on the interface.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.24.5
Configuring a Static RP Address
To configure a Static RP address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » multicast » dynamic » pim-sm » rp-address and click <Add dest-address>. The
Key Settings form appears.
Figure 650: RP Address Form
1. Address Box 2. Group Box 3. Add Button
3. Configure the following parameters as required:
Parameter Description
Address Static RP (Rendezvous Point) address.
Group The multicast group the RP handles.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
