Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
416 Deleting an Area Tag
Parameter Description
Area Password The area password to be used for transmission of level-1 LSPs.
Area Authentication Synopsis: send-only, validate
Default: send-only
The authentication option to be used with the area password on SNP PDUs. Default is
send-only.
Domain Authorization Synopsis: clear, md5
Default: clear
The authorization type for the domain password. Default is clear.
Domain Password The domain password to be used for transmission of level-2 LSPs.
Domain Authentication Synopsis: send-only, validate
Default: send-only
The authentication option to be used with the domain password on SNP PDUs. Default
is send-only.
6. Add one or more Network Entity Titles (NETs). For more information, refer to Section 5.18.10, “Managing
Network Entity Titles (NETs)”
7. If necessary, configure intervals for the generation of Link-State Packets (LSPs). The default is 30 seconds.
For more information, refer to Section 5.18.6, “Managing LSP Generation”.
8. If necessary, configure refresh intervals for Link-State Packets (LSPs). The default is 900 seconds. For more
information, refer to Section 5.18.9, “Managing LSP Refresh Intervals”.
9. If necessary, configure the minimum interval between consecutive SPF calculations. The default is 1 second.
For more information, refer to Section 5.18.7, “Managing SPF Calculations”.
10. If necessary, configure how long LSPs can reside in the device's Link State Database (LSDB) before they
are refreshed. The default is 1200 seconds. For more information, refer to Section 5.18.8, “Managing the
Lifetime of LSPs”.
11. If necessary, define rules for redistributing static, RIP, BGP or OSPF routes. For more information, refer to
Section 5.18.11, “Managing Redistribution Metrics”
12. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
13. Click Exit Transaction or continue making changes.
Section 5.18.4.3
Deleting an Area Tag
To delete an area tag for dynamic IS-IS routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » isis » area. The Area Tag table appears.
