Chapter 2
Using ROX II
RUGGEDCOM ROX II
User Guide
24 Dumping Raw Data to a Terminal or File
1
3
2
Figure 12: Specify Host Dialog Box
1. Address Box 2. Cancel Button 3. OK Button
4. Type the host's IP address in the Address box and click OK. The results of the ping action are displayed in
the Ping Result Window.
Section 2.6.2
Dumping Raw Data to a Terminal or File
Tcpdump is a packet analyzer for TCP/IP and other packets. It can be used to dump raw data to a terminal or file.
To dump raw data to a terminal or file, do the following:
1. Select the Tools menu and click Accessories.
2. Click Tcpdump. The Tcpdump screen appears.
