Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
480 Managing Prefix Lists and Entries
Figure 543: Advertised Route Table
The Advertised Route table provides the following information:
Parameter Description
Network The network.
Type The route type.
Sub Type The route sub type.
Nexthop Next hop.
Metric The metric value.
From Where this route comes from.
Tag Tag.
Time The route update time.
If no dynamic RIP routes have been configured, configure RIP and add routes as needed. For more information
about configuring RIP, refer to Section 5.20.1, “Configuring RIP”.
Section 5.20.3
Managing Prefix Lists and Entries
Neighbors can be associated with prefix lists, which allow the RIPs daemon to filter incoming or outgoing routes
based on the allow and deny entries in the prefix list.
The following sections describe how to configure and manage prefix lists and entries for dynamic RIP routes:
• Section 5.20.3.1, “Viewing a List of Prefix Lists”
• Section 5.20.3.2, “Viewing a List of Prefix Entries”
• Section 5.20.3.3, “Adding a Prefix List”
• Section 5.20.3.4, “Adding a Prefix Entry”
• Section 5.20.3.5, “Deleting a Prefix List”
• Section 5.20.3.6, “Deleting a Prefix Entry”
Section 5.20.3.1
Viewing a List of Prefix Lists
To view a list of prefix lists for dynamic RIP routes, navigate to one routing » dynamic » rip » filter. If prefix lists
have been configured, the Prefix List table appears.
