Viewing the Status of Dynamic RIP Routes 479
Figure 541: Route Table
The Route table provides the following information:
Parameter Description
Network The network.
Type The route type.
Sub Type The route sub type.
Nexthop The next hop.
Metric The metric value.
From Where this route comes from.
Tag Tag.
Time The route update time.
To view the name of the interface associated with the route, navigate to routing » status » rip » interface. The
Interface table appears.
Figure 542: Interface Table
The Interface table provides the following information:
Parameter Description
Name The name of the interface.
To view the routing information advertised to the network, navigate to routing » status » rip » route. The
Advertised Route table appears.
