RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Redistribution Metric 475
Figure 537: Redistribute Route From Other Protocols Form
1. Metric Box
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.19.11.3
Deleting a Redistribution Metric
To delete a redistribution metric for dynamic BGP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » redistribute. The Redistribute Route from Other Protocols table
appears.
Figure 538: Redistribute Route from Other Protocols Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen metric.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
