RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Routing Map Filter Entry 525
Figure 604: Route Map Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen filter.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.21.6.6
Deleting a Routing Map Filter Entry
To delete an entry for a route map filter, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » ospf » filter » route-map » {tag} » entry, where {tag} is the tag for the
route map filter. The Route Map Entry table appears.
Figure 605: Route Map Entry Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen entry.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
