Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
544 Deleting a Gateway for an IPv4 Static Route
Figure 631: Key Settings Form
1. Gateway Address Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Gateway Address The gateway for the static route.
5. Click Add to add the gateway address. The Static Route Using Gateway form appears.
Figure 632: Static Route Using Gateway Form
1. Distance Box
6. Configure the following parameter(s) as required:
Parameter Description
Distance (optional) The distance for the static route.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.22.6.4
Deleting a Gateway for an IPv4 Static Route
To delete a gateway for an IPv4 static route, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
