Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
574 Managing the Static Multicast Group Table
Figure 665: Router Ports Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen router port.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.25.5
Managing the Static Multicast Group Table
The following sections describe how to configure and manage a list of known static multicast groups on other
devices:
• Section 5.25.5.1, “Viewing a List of Static Multicast Group Entries”
• Section 5.25.5.2, “Adding a Static Multicast Group Entry”
• Section 5.25.5.3, “Deleting a Static Multicast Group Entry”
Section 5.25.5.1
Viewing a List of Static Multicast Group Entries
To view a list of entries for known static multicast groups on other devices, navigate to switch » mcast-filtering »
static-mcast-table. If entries have been configured, the Static Multicast Summary table appears.
Figure 666: Static Multicast Summary Table
If no entries have been configured, add entries as needed. For more information, refer to Section 5.25.5.2,
“Adding a Static Multicast Group Entry”.
