Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
466 Managing Networks
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.19.8
Managing Networks
As opposed to neighbors, which are specific routers with which to exchange routes, networks are groups of
routers that are either part of a specific subnet or connected to a specific network interface. They can be used at
the same time as neighbors.
NOTE
For point to point links, such as T1/E1 links, specify neighbors instead of a network. For more
information, refer to Section 5.19.7.2, “Adding a Neighbor”.
NOTE
Networks for the BGP protocol do not require a valid entry in the routing table. Since BGP is a broader
gateway protocol, a more general network specification would typically be entered. For example, if a
routed network inside the Autonomous System (AS) was comprised of many different Class C subnets
(/24) of the 192.168.0.0/16 range, it is more efficient to advertise the one Class B network specification,
192.168.0.0/16, to its BGP neighbors.
NOTE
If neighbors are specified but no networks are specified, the router will receive routing information from
its neighbors but will not advertise any routes to them. For more information about neighbors, refer to
Section 5.19.7, “Managing Neighbors”.
The following sections describe how to configure and manage networks:
• Section 5.19.8.1, “Viewing a List of Networks”
• Section 5.19.8.2, “Adding a Network”
• Section 5.19.8.3, “Deleting a Network”
• Section 5.19.8.4, “Tracking Commands”
Section 5.19.8.1
Viewing a List of Networks
To view a list of networks configured for the BGP protocol, navigate to routing » dynamic » bgp » network. If
networks have been configured, the BGP Network table appears.
Figure 525: BGP Network Table
