RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding an SNMP Security Model 273
Figure 280: SNMP Security Model to Group Mapping Table
If no SNMP security models have been configured, add security models as needed. For more information, refer to
Section 5.11.8.2, “Adding an SNMP Security Model”.
Section 5.11.8.2
Adding an SNMP Security Model
To add an SNMP security model, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to admin » snmp » snmp-security-to-group and click <Add snmp-security-to-group>. The Key
Settings form appears.
Figure 281: Key Settings Form
1. Security Model List 2. User Name List 3. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Security Model Synopsis: v1, v2c, v3
The SNMP security model to use: SNMPv1, SNMPv2c, or USM/SNMPv3.
User Name The security name (a ROX user name) for the SNMP group.
4. Click Add to create the protocol. The SNMP Security Model to Group Mapping screen appears.
