RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a VRRP Monitor 595
Figure 691: Monitor Interface Form
1. Weight Box
6. Configure the following parameter(s) as required:
Parameter Description
Weight The amount by which to increase or decrease the router's priority. When negative, the
priority decreases by this amount when the interface falls. When positive, the priority
increases by this amount when the interface is up. When not set, the state changes to
the fault state when the interface falls.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.26.7.3
Deleting a VRRP Monitor
To delete a VRRP monitor, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp » instance » {name} » monitor, where {name} is the name of the VRRP
instance. The Monitor Interface table appears.
Figure 692: Monitor Interface Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen monitor.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
