Chapter 2
Using ROX II
RUGGEDCOM ROX II
User Guide
28 Using the Command Line Interface
1
2
3
Figure 16: MPLS Traceroute Screen
1. Remote IP Address/Prefix Box 2. Start Button 3. Result Window
3. Type the IPv4 address in the Remote IP Address/Prefix box and click Start. The results of the trace are
displayed in the Result Window.
Section 2.7
Using the Command Line Interface
The Web interface includes a built-in Command Line Interface (CLI). To access the Command Line Interface
(CLI) from within the Web interface, select the Tools menu and click CLI. The CLI screen appears.
