RUGGEDCOM ROX II
User Guide
Chapter 4
System Administration
Configuring RADIUS Authentication for Switched Ethernet
Ports 217
Parameter Description
address The IPv4 address of the server.
port-udp Default: 1812
password Synopsis: The aes-cfb-128-encrypted-string works exactly like des3-cbc-encrypted-
string but AES/128bits in CFB mode is used to encrypt the string. The prefix for
encrypted values is '$4$'.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 4.8.3
Configuring RADIUS Authentication for Switched Ethernet
Ports
To configure RADIUS authentication for switched Ethernet ports, do the following:
IMPORTANT!
Passwords are case-sensitive.
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to switch » port-security » radius. The Primary Radius Server and Secondary Radius Server
forms appear.
Figure 230: Primary Radius Server Form
1. Address Box 2. Port UDP Box 3. Password Box
