Chapter 4
System Administration
RUGGEDCOM ROX II
User Guide
216 Configuring RADIUS Authentication for PPP Services
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to global » ppp » radius. The Primary Radius Server and Secondary Radius Server forms
appear.
Figure 228: Primary Radius Server Form
1. Address Box 2. Port UDP Box 3. Password Box
Figure 229: Secondary Radius Server Form
1. Address Box 2. Port UDP Box 3. Password Box
3. In both forms, configure the following parameters as required:
