RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Shared Network 317
Figure 335: Shared Network Configuration Table
If no shared networks have been configured, add shared networks as needed. For more information, refer to
Section 5.15.6.2, “Adding a Shared Network”.
Section 5.15.6.2
Adding a Shared Network
To add a shared network to the DHCP server, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » dhcpserver » shared-network and click <Add shared-network>. The Key
Settings form appears.
Figure 336: Key Settings Form
1. Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
name The unique name to refer to the host within a DHCP configuration.
4. Click Add to create the new shared network.
5. Configure options for the shared network. For more information, refer to Section 5.15.6.3, “Configuring
Shared Network Options”.
6. Configure the client for the shared network. For more information, refer to Section 5.15.6.4, “Configuring a
Shared Network Client”.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
