Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
630 Adding ESP Algorithms
Section 5.28.8.3
Adding ESP Algorithms
To add a new algorithm for the Encapsulated Security Payload (ESP) protocol, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » ipsec » connection » {connection} » esp » algorithm, where {connection} is the
name of the connection.
3. Click <Add agorithm>. The Key Settings form appears.
Figure 735: Key Settings Form
1. Cipher Algorithm Box 2. Hash Method Box 3. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Cipher Algorithm Synopsis: 3des, aes, aes256, aes192, aes128, any
The cipher algorithm. The default value is '3des' or 'aes' unless overwritten by the
default connection setting.
Hash Method Synopsis: sha1, md5, any
The hash method. The default value is 'sha1' or 'md5' unless overwritten by the default
connection setting.
5. Click Add to create the new algorithm.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.28.8.4
Deleting ESP Algorithms
To delete an algorithm for the Encapsulated Security Payload (ESP) protocol, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
To Next Page
