RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting an Interface 383
Figure 417: Broadcast Address Form
1. IPv4 Address Box 2. Auto Detect Check Box 3. None Check Box
3. Configure the following parameter(s) as required:
Parameter Description
ipv4-address An IPv4 address for a broadcast address.
detect Automatic detection of the broadcast address(es).
none The default.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.9.5
Deleting an Interface
To delete an interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwinterface, where {firewall} is the name of the
firewall. The Main Interface Settings table appears.
