Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
504 Managing Routing Interfaces
Figure 578: Redistribute Route from Other Protocols Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen metric.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.20.11
Managing Routing Interfaces
The following sections describe how to configure and manage routing interfaces for dynamic RIP routes:
• Section 5.20.11.1, “Viewing a List of Routing Interfaces”
• Section 5.20.11.2, “Configuring a Routing Interface”
Section 5.20.11.1
Viewing a List of Routing Interfaces
To view a list of routing interfaces for a RIP network, navigate to routing » dynamic » rip » interface. The
Interface Parameters table appears.
Figure 579: Interface Parameters Table
