Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
536 Adding a Message Digest Key
Section 5.21.10.2
Adding a Message Digest Key
To add a message digest key to an OSPF routing interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » ospf » interface » {name} » message-digest-key, where {name} is the
name of the routing interface.
3. Click <Add message-digest-key>. The Key Settings form appears.
Figure 620: Key Settings Form
1. Key ID Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Key ID The key ID.
5. Click Add to add the key. The Message Digest form appears.
Figure 621: Message Digest Form
1. Password (Key) Box
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
