Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
156 Clearing WAN Statistics
Parameter Description
Last Status Change The duration of time since last change of interface status.
For information about clearing the WAN statistics, refer to Section 3.24.4, “Clearing WAN Statistics”.
Section 3.24.4
Clearing WAN Statistics
The following describes how to clear the statistics collected when WAN interfaces are enabled. All of the statistics
or only those for a interface can be cleared.
To clear the statistics, do the following:
1. Navigate to interfaces » wan and click clearstatistics in the menu. The Clear Interface Statistics and
Trigger Action forms appear.
Figure 163: Clear Interface Statistics Form
1. DDS Interface List 2. T1/E1 Interface List 3. T3/E3 Interface List 4. All Interfaces CheckBox
Figure 164: Trigger Action Form
1. Perform Button
2. On the Clear Interface Statistics form, configuring the following parameter(s):
