Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
264 Deleting an SNMP Community
Figure 269: Key Settings Form
1. Community Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Community Name The SNMP community name.
4. Click Add to create the protocol. The SNMPv1/v2c Community Configuration screen appears.
Figure 270: SNMPv1/v2c Community Configuration Form
1. User Name List
5. Configure the following parameter(s) as required:
Parameter Description
User Name The SNMP community security name.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.11.5.3
Deleting an SNMP Community
To delete an SNMP community, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
