Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
444 Configuring Match Rules
Figure 492: Route Map Entry Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen entry.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.19.3.7
Configuring Match Rules
To configure match rules for a route map filter entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map » {tag} » entry » {number} » match, where
{tag} is the tag for the route map filter and {number} is the sequence number for the entry. The Match
Address of Route, Match Nexthop of Route, Match Advertising Source Address and Match forms
appear.
Figure 493: Match Address of Route Form
1. Prefix List List
