Viewing a List of Static Labels 807
Section 5.39.5.2
Viewing a List of Static Labels
To view a list of static labels, navigate to mpls » static-mpls » binding » {protocol}, where {protocol} is either
ipv4 or ipv6. If static labels have been configured, the Static MPLS Bindings for IPv4 Addresses or Static
MPLS Bindings for IPv6 Addresses table appears.
Figure 930: Static MPLS Bindings for IPv4 Addresses Table (Example)
If no static labels have been configured, add labels as needed. For more information about adding static labels,
refer to Section 5.39.5.3, “Adding a Static Label”.
Section 5.39.5.3
Adding a Static Label
To add a static label, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to mpls » static-mpls » binding » {protocol}, where {protocol} is either ipv4 or ipv6.
3. Click <Add dest-address> in the menu. The Key Settings form appears.
NOTE
A route to the destination address must already be present in the routing table.
Figure 931: Key Settings Form
1. Address Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Address The destination address/prefix.
