Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
108 Managing Routable Ethernet Ports
1. Navigate to interfaces » switch » {slot/port} » diagnostics and click clear-cable-stats-port in the menu.
The Trigger Action form appears.
Figure 109: Trigger Action Form
1. Perform Button
2. Click Perform to clear the statistics.
Section 3.19
Managing Routable Ethernet Ports
The following sections describe how to configure and manage routable Ethernet ports:
• Section 3.19.1, “Viewing a List of Routable Ethernet Ports”
• Section 3.19.2, “Configuring a Routable Ethernet Port”
Section 3.19.1
Viewing a List of Routable Ethernet Ports
To view a list of routable Ethernet ports, navigate to interface » eth. The Routable Ethernet Ports table
appears.
Figure 110: Routable Ethernet Ports Table
Section 3.19.2
Configuring a Routable Ethernet Port
To configure a routable Ethernet port, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
