RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing Interfaces 417
Figure 456: Area Tag Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen area tag.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.18.5
Managing Interfaces
IS-IS transmits hello packets and Link-State Packets (LSPs) through IS-IS enabled interfaces.
NOTE
IS-IS is only supported on Ethernet and WAN (HDLC-ETH) interfaces.
The following sections describe how to configure and manage interfaces for IS-IS:
• Section 5.18.5.1, “Viewing a List of Interfaces”
• Section 5.18.5.2, “Configuring an Interface”
Section 5.18.5.1
Viewing a List of Interfaces
To view a list of interfaces for dynamic IS-IS routes, navigate to routing » dynamic » isis » interface. If
interfaces have been configured, the Interface Parameters table appears.
Figure 457: Interface Parameters Table
