Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
816 Configuring LDP
Parameter Description
Peer ID The peer ID of the LDP neighbor discovery.
Peer IP The peer ID of the LDP neighbor discovery.
Interface The local IP address of the LDP neighbor discovery.
Local IP LDP neighbor discovery state.
P Holdtime The peer holdtime of the LDP neighbor discovery.
P Keepalive Interval The peer keepalive interval of the LDP neighbor discovery.
Section 5.39.7.6
Configuring LDP
To configure the LDP, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to mpls » ldp. The Label Discovery Protocol (LDP) Configuration form appears.
Figure 944: Label Discovery Protocol (LDP) Configuration Form
1. Enabled Check Box 2. Holdtime Box
3. Configure the following parameter(s) as required:
Parameter Description
Enable LDP Default: false
A boolean flag to indicate that Label Distribution Protocol (LDP) is enabled.
Prerequisite: MPLS must be enabled before enabling LDP.
Prerequisite: MPLS static bindings must be removed before enabling LDP.
LDP Holdtime Default: 180
The time (in seconds) for which a Label Distribution Protocol (LDP) session is
maintained in the absence of LDP messages from the session peer.
