Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
550 Adding a Static Multicast Group
Section 5.23.2.2
Adding a Static Multicast Group
To add a static multicast group, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » multicast » static » mcast-groups and click <Add mcast-groups>. The Key
settings form appears.
Figure 641: Key Settings Form
1. Description Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
description Describes the multicast group, spaces are not allowed.
4. Click the Add button. The Multicast Group Configuration form appears.
Figure 642: Multicast Group Configuration Form
1. Source-ip Box 2. Multicast-ip Box 3. In-interface List 4. Hw-accelerate Check Box
