RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of NETs 431
• Section 5.18.10.1, “Viewing a List of NETs”
• Section 5.18.10.2, “Adding a NET”
• Section 5.18.10.3, “Deleting a NET”
Section 5.18.10.1
Viewing a List of NETs
To view a list of NETs configured for an IS-IS area, navigate to routing » dynamic » isis » area » {name} » net,
where {name} is the unique name for the area. The Network Entity Title table appears.
Figure 475: Network Entity Title Table
If no NETs have been configured, add NETs as needed. For more information, refer to Section 5.18.10.2, “Adding
a NET”.
Section 5.18.10.2
Adding a NET
To add a Network Entity Title (NET) for an IS-IS area, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » isis » area » {name} » net, where {name} is the unique name for the
area.
3. Click <Add net>. The Key Settings form appears.
Figure 476: Key Settings Form
1. Net-title Box 2. Add Button
4. Configure the following parameter(s) as required:
