Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
86 Adding an Event Tracker
Figure 88: Statistics Form
1. Echo Attempts 2. Echo Replies 3. Min RTT 4. Average RTT 5. Max RTT 6. Standard Deviation RTT
This form provides the following information:
Parameter Description
Echo Attempts The number of echo attempts.
Echo Replies The number of echo replies.
Min RTT The minimum of the round trip time (in milliseconds).
Average RTT The average of the round trip time (in milliseconds).
Max RTT The maximum of the round trip time (in milliseconds).
Standard Deviation RTT The standard deviation of the round trip time (in milliseconds).
Section 3.17.3
Adding an Event Tracker
To add an event tracker, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to global » tracking and click <Add event>. The Key Settings form appears.
