RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Host 387
Section 5.17.10.3
Deleting a Host
To delete a host, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwhost, where {firewall} is the name of the firewall.
The Main Host Settings table appears.
Figure 423: Main Host Settings Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen host.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.11
Managing Policies
Policies define the default actions for establishing a connection between different firewall zones. Each policy
consists of a source zone, a destination zone and an action to be performed when a connection request is
received.
The following example illustrates the policies for establishing connections between a local network and the
Internet.
Table: Example
Policy Source Zone Destination Zone Action
1 Loc Net ACCEPT
2 Net All DROP
3 All All REJECT
Each policy controls the connection between the source and destination zones. The first policy accepts all
connection requests from the local network to the Internet. The second policy drops or ignores all connection
requests from the Internet to any device on the network. The third policy rejects all other connection requests and
sends a TCP RST or an ICMP destination-unreachable packet to the client.
