Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
386 Adding a Host
Figure 421: Host Options Form
1. IPsec Zone Check Box
Figure 422: Main Host Settings Form
1. Zone List 2. Interface List 3. IP Address Box 4. Description Box
6. On the Host Options form, configure the following parameter(s) as required:
Parameter Description
IPSec zone Default: false
7. On the Main Host Settings form, configure the following parameter(s) as required:
Parameter Description
Zone A pre-defined zone
Interface A pre-defined interface to which optional IPs and/or networks can be added.
IP Address List (Optional) Additional IP addresses or networks - comma separated.
description (Optional) The description string for this host.
8. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
9. Click Exit Transaction or continue making changes.
