Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
594 Adding a VRRP Monitor
Figure 689: Monitor Interface Table
If no VRRP monitors have been configured, add monitors as needed. For more information, refer to
Section 5.26.7.2, “Adding a VRRP Monitor”.
Section 5.26.7.2
Adding a VRRP Monitor
To add a VRRP monitor, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp » instance » {name} » monitor, where {name} is the name of the VRRP
instance.
3. Click <Add monitor>. The Key Settings form appears.
Figure 690: Key Settings Form
1. Extra Interface to Monitor Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Extra Interface to Monitor The name of the interface.
5. Click Add to add the monitor. The Monitor Interface form appears.
