Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
652 Adding a Remote Daemon
Figure 765: Remote Daemon of Goose Tunnel Table
If no remote daemons have been configured, add daemons as needed. For more information, refer to
Section 5.29.6.2, “Adding a Remote Daemon”.
Section 5.29.6.2
Adding a Remote Daemon
To configure a remote daemon for a GOOSE tunnel, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » l2tunneld » goose » {tunnel} » remote-daemon, where {tunnel} is the name of the
GOOSE tunnel.
3. Click <Add remote-daemon>. The Key Settings form appears.
Figure 766: Key Settings Form
1. IP Address Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
ip-address The IP address of the remote Layer 2 protocol server.
5. Click Add to create the daemon.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
