RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Host 385
Figure 419: Main Host Settings Table
If no hosts have been configured, add hosts as needed. For more information, refer to Section 5.17.10.2, “Adding
a Host”.
Section 5.17.10.2
Adding a Host
To add a new host for a firewall, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwhost, where {firewall} is the name of the firewall.
3. Click <Add fwhost> in the menu. The Key Settings form appears.
Figure 420: Key Settings Form
1. Name Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
name The name of a host configuration entry.
5. Click Add. The Host Options and Main Host Settings forms appear.
