RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing the Status of PIM-SM 561
Figure 653: RP Candidate Form
1. Local Address Box 2. Timer Box 3. Priority Box
4. Configure the following parameters as required:
Parameter Description
Local Address Local address to be used in the Cand-RP messages. If not specified, the largest local IP
address will be used (excluding passive interfaces).
Timer Default: 60
The number of seconds to wait between advertising Cand-RP message.
Priority Priority of this CRP, smaller value means higher priority.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.24.7
Viewing the Status of PIM-SM
To view the status of PIM-SM, do the following:
1. Navigate to routing » status » pim-sm. The PIM-SM Status form appears displaying the address of the
BSR.
